Truss Frames - Full Taper

The Truss Frames - Full Taper from American Muscle Docks & Fabrication is a rectangular metal frame, about 3 feet long, shown against a black background—perfect for adjustable dock ramps and related uses. Truss Frame - Full Taper - American Muscle Docks & Fabrication The Truss Frames - Full Taper by American Muscle Docks & Fabrication, a 4-foot adjustable rectangular metal frame with triangular supports, is shown against a black background. Truss Frame - Full Taper - American Muscle Docks & Fabrication The American Muscle Docks & Fabrication Truss Frames - Full Taper is a rectangular, adjustable truss frame with cross-bracing, shown against a black background and labeled as 6 ft. The American Muscle Docks & Fabrication Truss Frames - Full Taper, a 6-foot rectangular metal frame with cross-bracing, is showcased against a black background. Truss Frame - Full Taper - American Muscle Docks & Fabrication

Truss Frames - Full Taper

Construct durable and adjustable dock ramps with our Full Taper Truss Frames. Designed to accommodate fluctuating water levels or shorelines, these robust frames taper from a 12" height to a compact 5" height. For added convenience and ease of movement, optional rollers can be integrated into the frame design.

Optional UHMW Roller Assembly Available
Request A Quote

Request A Quote

Why Choose Our Frames?

We use more steel and more welds than our competitors. All corners and structural areas of our dock truss frames are designed for maximum strength. Instead of cheapening out on metal or using less effective welding techniques such as edge or butt-welding, our corners are mitred and seam-welded to create a rigid box frame that is superior in strength. These quality differences are easily recognizable when compared to other steel truss docks or aluminum truss dock frames out there. We build to last!

Optional UHMW roller assembly available.

SPECIFICATIONS
› We are the manufacturer
› Frames tapered from 12" to 5"
› 1-1/2" x 1-1/2" x 3/16" steel angle
› 2" steel available through special order
› Gussets used for rigid strength
› Pre-punched holes positioned further from the edge and elongated
› All metal is galvanized to prevent rusting
› Frames can be bolted directly together or with our hardware

Stacks of metal racks filled with black rectangular containers are arranged outdoors on a gravel surface, with trees and blue sky in the background.
steel truss frame full taper floating dock American Muscle Docks
Close-up of intersecting galvanized metal beams with a triangular support, showing bolt holes and some surface scratches.
steel truss frame full taper floating dock American Muscle Dock
Stacks of metal scaffolding or structural steel frames are arranged outdoors on a concrete surface under a cloudy sky.
Close-up of galvanized steel components joined together with welds, including flat plates, a rod, and metal beams with bolt holes.
A metal frame structure sits on top of black rectangular plastic bases on grass, possibly forming the foundation for a greenhouse or similar outdoor structure.
Stacks of metal racks filled with black rectangular containers are arranged outdoors on a gravel surface, with trees and blue sky in the background.
steel truss frame full taper floating dock American Muscle Docks
Close-up of intersecting galvanized metal beams with a triangular support, showing bolt holes and some surface scratches.
steel truss frame full taper floating dock American Muscle Dock
Stacks of metal scaffolding or structural steel frames are arranged outdoors on a concrete surface under a cloudy sky.
Close-up of galvanized steel components joined together with welds, including flat plates, a rod, and metal beams with bolt holes.
A metal frame structure sits on top of black rectangular plastic bases on grass, possibly forming the foundation for a greenhouse or similar outdoor structure.
0/0

Details

Sizes

Specifications

Shipping

3'W x 10'L

168 lbs.

4'W x 10'L

198 lbs.

5'W x 10'L

230 lbs.

6'W x 10'L

251 lbs.

Note: Pricing does not include delivery. Please use the Quote Request form for a full quote that includes shipping.

Shipping

We ship domestic and international. All shipping lines are third-party companies. AMD has no affiliation with and cannot be held responsible for its actions. Any changes to destination and/or uncommunicated delivery constraints may result in a back-charged fee.

Shipping & Returns

We are the manufacturer

Frames tapered from 12" to 5"

Optional UHMW roller assembly available

1-1/2" x 1-1/2" x 3/16" steel angle

2" steel available through special order

Gussets used for rigid strength

Pre-punched holes positioned further from the edge and elongated

All metal is galvanized to prevent rusting

Frames can be bolted directly together or with our hardware

Note: Dimensions and drawings are for illustration purposes only. Some actual dimensions may vary slightly from what is shown.
